◆SIZE FOR FULL BED
FULL LENGTH 223㎝
FULL WIDTH 105㎝
INCLUDING THE SIDE RAIL 45㎝
WITHOUT THE SIDE RAIL 4.5㎝
◆SIZE FOR BED SURFACE
LENGTH FOR SURFACE 196㎝
WIDTH FOR SURFACE 90㎝
BED base HEIGHT RANGE
MAXIMUM HEIGHT 70㎝
MINIMUM HEIGHT 45㎝
◆BASIC PARAMETER
BACK SECTION PANEL 0°～≥70°
LEG SECTION PANEL 0°～≥30°
TRENDELENBURG 0°～≥12°
ANTI-TRENDELENBURG 0°～≥12°
◆ LOADING CAPACITY
(均布) MAXIMUM STATIC SAFE LOAD 400Kg
MAXIMUM DYNAMIC SAFE LOAD 170Kg
◆CONFIGRATION
DIAMETER OF CENTRALLY SILENT CASTOR φ12.5㎝
NURSE CONTROLLER
DETACHABLE PP HEAD AND FOOT BOARD
ANGLE INDICATER
(CPR) CPR HANDLE
MATTRESS (OPTIONAL)
IV POLE (OPTIONAL)
TOP COAT: ELECTROSTATIC POWDER COATING
BED frame: COLD-ROLLED STEEL TUBE
BED base: COLD-ROLLED STEEL SHEET
