◆ SIZE FOR FULL BED
FULL LENGTH 223㎝
FULL WIDTH
INCLUDING THE SIDE RAIL 105㎝
WITHOUT THE SIDE RAIL 99㎝
◆ SIZE FOR BED SURFACE
LENGTH FOR SURFACE 196㎝
WIDTH FOR SURFACE 90㎝
BED base HEIGHT RANGE
MAXIMUM HEIGHT 76㎝
MINIMUM HEIGHT 52㎝
◆BASIC PARAMETER
BACK SECTION PANEL 0°～≥70°
LEG SECTION PANEL 0°～≥30°
TRENDELENBURG 0°～≥12°
ANTI-TRENDELENBURG 0°～≥12°
◆LOADING CAPACITY
MAXIMUM STATIC SAFE LOAD 400Kg
MAXIMUM DYNAMIC SAFE LOAD 170Kg
◆ CONFIGRATION
DIAMETER OF CENTRALLY SILENT CASTOR φ12.5㎝
NURSE CONTROLLER
RAIL CONTROLLER
DETACHABLE PP HEAD AND FOOT BOARD
PP SIDE RAIL
ANGLE INDICATER
(CPR) CPR HANDLE
MATTRESS (OPTIONAL)
IV POLE (OPTIONAL)
WEIGHT READING SYSTEM (OPTIONAL)
ACCURACY OF MEASUREMENT 0.1Kg
OPTIONAL 0.05Kg 0.02Kg
TOP COAT: ELECTROSTATIC POWDER COATING
BED frame: COLD-ROLLED STEEL TUBE
BED base: COLD-ROLLED STEEL SHEE
